Splash Guard: Service and Repair
- Make
- Buick
- Model
- LaCrosse
- Engine
- V8-5.3L
- Year
- 2008
- Section
- Splash Guard › Service and Repair
Body and FrameService and Repair · page 1 of 2
Splash Guard: Service and Repair
Engine Splash Shield Replacement
Tools Required
J 38778 Door Trim Pad and Garnish Clip Remover
Removal Procedure
1. Remove the push-in retainers that hold the ABS lead to the engine splash shield.
2. Use the J 38778 in order to remove the push-in retainers from the engine splash shield.
3. Remove the engine splash shield from the lower flange of the engine compartment side rail.
Installation Procedure
