Knock Sensor: Locations

Make

Buick

Model

Lucerne

Engine

V6-3.8L

Year

2007

Section

Ignition System › Knock Sensor › Locations

Powertrain ManagementLocations · page 1 of 2

Knock Sensor: Locations

Engine Controls Component Views

Rear of the Engine (L26)

1 - Evaporative Emission (EVAP) Canister Purge Solenoid Valve
2 - Throttle Actuator Control (TAC) Module
3 - Exhaust Gas Recirculation (EGR) Valve
4 - Fuel Injector 6
5 - Fuel Injector 4
6 - Fuel Injector 2
7 - Manifold Absolute Pressure (MAP) Sensor
8 - Camshaft Position (CMP) Sensor
9 - Engine Oil Pressure (EOP) Sensor
10 - Knock Sensor (KS) 2
11 - Heated Oxygen Sensor (HO2S) 1

Front of the Engine (L26)
