Lucerne V6-3.9L (2009)
Power Seat Switch: Locations
Passenger Compartment/Roof Component Views
Driver Seat (KB6)
1 - Seat Back Ventilation Heat and Cool Module - Driver (KB6)
2 - Inflatable Restraint Side Impact Module - Left
3 - Seat Lumbar Massage Motor - Driver (AM3)
4 - Lumbar Adjuster Switch - Driver (AE8, A45)
5 - Seat Adjuster Switch - Driver (AE8, A45)
6 - Seat Adjuster Motor Assembly - Driver (AE8, A45)
7 - Memory Seat Module (MSM) (A45)
8 - Auxiliary Power Outlet (A51)
9 - Seat Cushion Ventilation Heat and Cool Module - Driver (KB6)
10 - Seat Recline Motor - Driver (AE8, A45)
11 - Seat Lumbar Motor - Driver (AE8)
Passenger Seat
