Riviera V6-231 3.8L VIN C SFI (1989)
7.
Locate and attach spacers, Part Number 20603560, around window opening. For Rivieras, refer to Figure 1. For 1985-1989 Electras and LeSabres,
refer to Figure 2.
8.
Position windshield glass into opening. Align for uniform fit to roof and windshield pillars.
With glass in proper position in opening, apply a piece of masking tape over edge of glass and adjacent body pillar. Slit tape vertically at edge of
glass. During installation, tape on glass can be aligned with tape on body to guide glass onto desired position.
9.
Remove windshield from body and prep as follows utilizing primers contained in the urethane repair kit number 9636067:
