Catera V6-3.0L VIN R (1997)
17.
Remove the door hinge pins using Kent Moore Tool J 42081. See Figure 1.
18.
Remove the door.
19.
Remove the check link.
20.
Drill out the check link bracket welds and remove bracket. See Figure 2.
21.
Cut one of the two reinforcement plates on each side by 10 mm (3/8 in). See Figure 3.
22.
Pre-paint both reinforcement plates and new check link bracket.
