Catera V6-3.0L VIN R (1997)

Page 1
background image

Trunk / Liftgate Interior Trim Panel: Service and Repair
Compartment Lid Trim Replacement: Rear

REMOVAL PROCEDURE

Compartment Lid Trim Replacement - Rear: Removal Procedure

Tools Required
J 38778 Door Trim Pad and Garnish Clip Remover
1. Remove twenty retainers using J 38778 from the compartment lid finish panel.
2. Remove the compartment lid finish panel.

INSTALLATION PROCEDURE

Compartment Lid Trim Replacement - Rear: Installation Procedure

1. Install the rear compartment lid finish.
2. Install the retainers to the rear compartment lid finish panel.
