Catera V6-3.0L VIN R (1997)
Seat Cushion: Service and Repair
Seat Cushion Trim Cover Replacement: Rear
REMOVAL PROCEDURE
Seat Cushion Trim Cover Replacement (Rear): Removal Procedure
1. Remove the rear seat cushion.
2. Remove retainer rings form the seat cushion cover and from the frame.
Put down a protective cover to prevent damage to rear seat cushion cover.
Seat Cushion Trim Cover Replacement (Rear): Removal Procedure
3. Remove the rear seat cushion cover.
4. Unroute seat cushion heating element wiring from seat cushion pad.
INSTALLATION PROCEDURE
