Catera V6-3.0L VIN R (1997)
Seat Heater: Service and Repair
Seat Back Heater Replacement: Rear
REMOVAL PROCEDURE
Seat Back Heater Replacement (Rear): Removal Procedure
1. Remove the rear seatback cushion.
2. Remove the rear seatback cushion cover.
3. Remove seatback cushion heater element by:
3.1. Cut along seams on the inside of the seat cover, being careful not to cut through the front side of the seat cover.
3.2. Cut the heater element electrical wiring.
3.3. Remove the heater element and wiring from the seatback cover.
INSTALLATION PROCEDURE
Seat Back Heater Replacement (Rear): Installation Procedure
1. Install the rear seatback cushion heating element to the seatback cover.
