Catera V6-3.0L VIN R (1997)
Hydraulic Control Assembly - Antilock Brakes: Service and Repair
Brake Pressure Modulator Valve Bracket Replacement
REMOVAL PROCEDURE
1. Disconnect the negative battery cable.
2. Remove the EBTCM from the BPMV. Refer to EBTCM Replacement.
3. Remove the BPMV from the bracket. Refer to Brake Pressure Modulator Valve Replacement.
4. Remove the three bolts/screws (1) attaching the bracket (2) to the frame side member.
5. Remove the bracket (2) from the vehicle. Transfer the heat shield if replacing the bracket.
INSTALLATION PROCEDURE
1. Install the bracket (2) by attaching to the frame using three bolts/screws (1).
-
Tighten the three bolts/screws to 10 Nm (7 ft. lbs.).
-
Refer to Fastener Notice in Service Precautions.
2. Install the BPMV to the bracket. Refer to Brake Pressure Modulator Valve Replacement.
3. Install the EBTCM to the BPMV. EBTCM Replacement.
4. Reconnect the negative battery cable.
