Cadillac Workshop Service and Repair Manuals > Catera V6-3.0L VIN R (1997) > Engine, Cooling and Exhaust | Cooling System | Engine - Coolant Temperature Sensor/Switch | Coolant Temperature Sensor/Switch (For Computer) | Component Information | Specifications | Electrical Specifications

Electrical Specifications|Page 2243 > < 01-06-02-005|Page 2240

Page 1

background image

Temperature Vs Resistance Table

Engine, Cooling and Exhaust
Cooling System
Engine - Coolant Temperature Sensor/Switch / Coolant Temperature Sensor/Switch (For Computer) / Component Information
Specifications
Electrical Specifications
