Catera V6-3.0L VIN R (1997)
Intake Manifold: Specifications
Intake Manifold Torque and Sequence
TIGHTENING SPECIFICATIONS
* Manifold Bolt ........................................................................................................................................................................................ 20 Nm (15 ft. lbs.)
Manifold Spacer Bolt ........................................................................................................................................................................... 20 Nm (15 ft. lbs.)
Plenum Bolt ......................................................................................................................................................................................... 8 Nm (71 inch lbs.)
Plenum Switch-Over Valve Bolt ......................................................................................................................................................... 8 Nm (71 inch lbs.)
* The manufacture does not provide a torque sequence for this component.
