Catera V6-3.0L VIN R (1997)
Door Switch: Service and Repair
Door Jamb Switch Replacement (Rear)
REMOVAL PROCEDURE
Door Jamb Switch Replacement (Rear): Removal Procedure
1. Remove the jamb switch screw.
2. Disconnect the jamb switch connectors.
3. Remove the jamb switch.
INSTALLATION PROCEDURE
Door Jamb Switch Replacement (Rear): Installation Procedure
1. Plug in the jamb switch.
2. Install the jamb switch screw.
Tighten
Tighten door jamb switch screw until fully seated but not stripped.
