Catera V6-3.0L VIN R (1997)
Headlamp Switch: Service and Repair
REMOVAL PROCEDURE
Headlamp Switch Replacement: Removal Procedure
1. Remove Headlamp switch from instrument panel by prying on left side of switch.
IMPORTANT: To ensure instrument panel trim is not damaged, place a cloth behind prying tool when removing.
2. Remove switch from instrument panel.
INSTALLATION PROCEDURE
Headlamp Switch Replacement: Installation Procedure
1. Install headlamp switch into dash seating fully.
2. Verify switch operation.
