Catera V6-3.0L VIN R (1997)
31. Connect the deployment harness to the 8-way passenger seat connector C316, located under the RH front seat track cover.
32. Route the deployment harness out of the RH side of the vehicle.
33. Stretch the LH pretensioner harness to full length.
34. Stretch the RH pretensioner harness to full length.
35. Place a power source, 12V minimum/2A minimum (i.e., a vehicle battery) near the shorted end of the harnesses.
36. Separate the two ends of the LH seat belt pretensioner deployment harness wires.
37. Connect the LH seat belt pretensioner deployment harness wires to the power source in order to deploy the LH seat belt pretensioner.
38. Disconnect the LH seat belt pretensioner deployment harness wires from the power source.
39. Twist together one end of each wire on the LH pretensioner deployment harness in order to short the wires.
Description
40. Separate the two ends of the RH seat belt pretensioner deployment harness wires.
41. Connect the RH seat belt pretensioner deployment harness wires to the power source in order to deploy the RH seat belt pretensioner.
42. Disconnect the RH seat belt pretensioner deployment harness wires from the power source.
43. Twist together one end of each wire on the RH pretensioner deployment harness in order to short the wires.
44. Disconnect the harnesses from the vehicle.
45. Discard the harnesses.
46. Scrap the vehicle in the same manner as a non-SIR equipped vehicle.
