Catera V6-3.0L VIN R (1997)
15. Remove the spring seats from the springs.
INSTALLATION PROCEDURE
1. Install the spring seats to the spring.
Important: Be sure that the spring leg is properly installed within the spring seats or noises may occur.
2. Install the rear springs to the lower control arm and body.
3. Raise the rear differential into place.
4. Align and place the protective shields.
NOTICE: Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners
requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use
paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint
clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid
damage to parts and systems.
5. Secure the rear differential with the cradle mount bolts.
^
Tighten the rear axle cradle mounts to the vehicle body bolts to 65 Nm (48 ft. lbs.).
6. Lower the support.
7. Place the support under the left side lower control arm.
8. Raise the support to allow for alignment of the lower shock absorber mount bolt.
9. Install the shock absorber lower mount bolt.
^
Tighten the shock absorber lower mount bolt to 110 Nm (81 ft. lbs.).
10. Lower the support.
11. Place the support under the right side lower control arm.
12. Raise the support to allow for alignment of the lower shock absorber mount bolt.
13. Install the lower shock absorber mount bolt.
^
Tighten the lower shock absorber mount bolt to 110 Nm (81 ft. lbs.).
14. Install the rear wheel speed sensor electrical connections.
15. Support the exhaust system with rubber insulators to the hangers.
16. Install the stabilizer shaft link to the lower control arms.
17. Install the stabilizer shaft link bolts.
^
Tighten the stabilizer shaft link bolts to 20 Nm (15 ft. lbs.).
18. Install the brake pipes to the lower control arms.
19. Secure the brake pipes with the retainers.
20. Lower the vehicle.
21. Adjust the rear toe specifications.
