Catera V6-3.0L VIN R (1997)
7. Remove the brake pipe from the lower control arm.
8. Remove the rear brake caliper.
9. Suspend the rear brake caliper. The brake system remains closed.
10. Remove the brake disc rotor set screw.
11. Remove the brake disc rotor. It may be necessary to back off the parking brake adjustment to remove the brake disc rotor.
12. Use the J 42072 to back out three of the four brake backing plate bolts to approximately nine complete revolutions or about 12 mm (0.47 in). This
will allow for the rear wheel hub puller pin installation.
13. Attach the J 42094-2 and attach the J 42094-1 to the rear wheel hub flange to hold the rear wheel hub while removing the rear wheel hub nut. Use
the drive shaft bolts if necessary.
