CTS V8-5.7L VIN P (2004)
9. Strip the nylon coating from the brake pipe end to be flared, if necessary.
^
Select the appropriate blade on the coating stripping tool included in the J 45405 , by unthreading the blade block from the stripping tool and
installing the block with the desired blade facing the tool rollers.
^
6.35 mm (0.250 inch) blade for 4.76 mm (3/16 inch) diameter pipe
^
9.50 mm (0.374 inch) blade for 6.35 mm (1/4 inch) diameter pipe
^
Insert the brake pipe end to be flared into the stripping tool to the depth of the ledge on the tool rollers.
^
While holding the brake pipe firmly against the stripping tool roller ledges, rotate the thumb-wheel of the tool until the blade contacts the brake
pipe coated surface.
Important: Do not gouge the metal surface of the brake pipe.
^
Rotate the stripping tool in a clockwise direction, ensuring that the brake pipe end remains against the tool roller ledges.
^
After each successive revolution of the stripping tool, carefully rotate the thumb-wheel of the tool clockwise, in order to continue stripping the
coating from the brake pipe until the metal pipe surface is exposed.
^
Loosen the thumb-wheel of the tool and remove the brake pipe.
Important: Ensure that all loose remnants of the nylon coating have been removed from the brake pipe.
^
Inspect the stripped end of the brake pipe to ensure that the proper amount of coating has been removed.
^
6.35 mm (0.250 inch) for 4.76 mm (3/16 inch) diameter pipe
^
9.50 mm (0.374 inch) for 6.35 mm (1/4 inch) diameter pipe
10. Chamfer the inside and outside diameter of the pipe with the de-burring tool included in the J 45405 .
11. Install the tube nuts on the brake pipe, noting their orientation.
12. Clean the brake pipe and the J 45405 of lubricant, contaminants, and debris.
