Flywheel: Service and Repair

Flywheel: Service and Repair

Engine Flywheel Replacement

Removal Procedure

1. Remove the transmission. Refer to Transmission Replacement (Rear Wheel Drive)  (See: Automatic Transmission/Transaxle/Service and

Repair/Removal and Replacement)Transmission Replacement (All Wheel Drive)  (See: Automatic Transmission/Transaxle/Service and
Repair/Removal and Replacement) .

2. Remove the engine flywheel bolts and the flywheel. Refer to Engine Flywheel Removal (Automatic Transmission)  (See: Engine, Cooling and

Exhaust/Engine/Service and Repair/Overhaul)Engine Flywheel Removal (Manual Transmission)  (See: Engine, Cooling and
Exhaust/Engine/Service and Repair/Overhaul) .

3. Clean and inspect the flywheel. Refer to Engine Flywheel Cleaning and Inspection (Automatic Transmission)  (See: Engine, Cooling and

Exhaust/Engine/Service and Repair/Overhaul)Engine Flywheel Cleaning and Inspection (Manual Transmission)  (See: Engine, Cooling and
Exhaust/Engine/Service and Repair/Overhaul) . If the flywheel teeth are damaged, inspect the starter for proper operation. Replace the starter if
you find excessive wear or damage to the starter drive. Refer to Starter Motor Replacement (LY7)  (See: Starting and Charging/Starting
System/Starter Motor/Service and Repair) .

Installation Procedure

1. Install the engine flywheel. Refer to Engine Flywheel Installation (Automatic Transmission)  (See: Engine, Cooling and Exhaust/Engine/Service

and Repair/Overhaul)Engine Flywheel Installation (Manual Transmission)  (See: Engine, Cooling and Exhaust/Engine/Service and
Repair/Overhaul) .

2. Install the transmission. Refer to Transmission Replacement (Rear Wheel Drive)  (See: Automatic Transmission/Transaxle/Service and

Repair/Removal and Replacement)Transmission Replacement (All Wheel Drive)  (See: Automatic Transmission/Transaxle/Service and
Repair/Removal and Replacement) .
