DeVille V8-273 4.5L (1989)
Brake Pad: Service and Repair
Removal
Fig. 2 Delco-Moraine 3200 Series Caliper Exploded View.
1.
Remove caliper assembly as outline above.
2.
Remove shoe and lining assemblies from caliper, Figs. 1 through 3, noting the following:
a. On models with tab mount outer shoe (all except series 3264), straighten bent over shoe tabs with suitable pliers.
b. On models with spring mount outer shoe (series 3264), insert screwdriver between shoe and caliper and disengage buttons on shoe from
holes in caliper.
3.
Remove sleeves and bushings from grooves in caliper mounting bolt holes, Figs. 1 through 3.
