DeVille DTS V8-4.6L VIN 9 (2002)
Front Fender Liner: Service and Repair
Wheelhouse Liner Replacement - Front
Removal Procedure
1. Remove the front fascia extension. Refer to Fascia Extension Replacement - Front (See: Bumper/Front Bumper/Front Bumper Cover /
Fascia/Service and Repair/Fascia Extension Replacement - Front) in Bumpers.
2. Remove all push in retainers securing the wheelhouse liner to the vehicle.
3. Remove the front wheelhouse liner from the vehicle.
Installation Procedure
1. Install the front wheelhouse liner to the vehicle.
2. Instal the push in retainers in order to secure the front wheelhouse liner to the vehicle.
3. Install the front fascia extension. Refer to Fascia Extension Replacement - Front (See: Bumper/Front Bumper/Front Bumper Cover /
Fascia/Service and Repair/Fascia Extension Replacement - Front) in Bumpers.
