DTS V8-4.6L VIN Y (2006)
Air Cleaner Fresh Air Duct/Hose: Service and Repair
AIR CLEANER OUTLET DUCT REPLACEMENT
REMOVAL PROCEDURE
1. Disconnect the engine harness electrical connector from the mass air flow (MAF)/intake air temperature (IAT) sensor.
2. Disconnect the positive crankcase ventilation (PCV) fresh air tube quick connect fitting from the air cleaner outlet duct.
