DTS V8-4.6L VIN Y (2006)
Power Steering Line/Hose: Service and Repair
Power Brake Booster Outlet Hose Replacement
Power Brake Booster Outlet Hose Replacement
Removal Procedure
1. Place a drain pan under the vehicle to catch the power steering fluid.
2. Remove the master cylinder retaining nuts and position the master cylinder (2) approximately six inches away from the hydro boost unit.
3. Remove the power steering pressure outlet hose from the hydro boost unit.
4. Raise and support the vehicle. Refer to Vehicle Lifting.
5. Remove the power steering pressure outlet hose (1) from the power steering gear.
6. Remove the power steering pressure outlet hose (2) from the vehicle.
Installation Procedure
1. Install the power steering pressure outlet hose (2) to the vehicle.
2. Notice: Refer to Fastener Notice in Service Precautions.
Install the power steering pressure outlet hose (1) to the power steering gear.
Tighten the power steering pressure outlet hose to the power steering gear to 27 Nm (20 ft. lbs.).
3. Lower the vehicle.
