Seville V8-4.6L VIN Y (2003)
Accumulator HVAC: Service and Repair
ACCUMULATOR REPLACEMENT
TOOLS REQUIRED
J 39400-A Halogen Leak Detector
REMOVAL PROCEDURE
1. Recover the refrigerant from the system.
2. Remove the suction hose retainer from the accumulator.
3. Remove the suction hose from the accumulator.
