Page 2
background image

6. Remove the oil pan drain plug.
7. Allow the oil to drain completely.

Installation Procedure

Notice: Refer to Fastener Notice.

1. Install the oil pan drain plug and NEW O-ring seal.

Tighten the oil pan drain plug to 20 N.m (15 lb ft).

2. Lower the vehicle.
