5. Install the push-on retaining nut to the steering column bracket stud.
6. Align the I/P courtesy lamp to the closeout panel opening, then push to secure the lamp.
Closeout/Insulator Panel Replacement - Right
Closeout/Insulator Panel Replacement - Right
Removal Procedure
1. Using a flat bladed tool, carefully pry the I/P courtesy lamp assembly from the right lower closeout panel.
2. Remove the push-in retainers on the right lower closeout panel from the I/P lower support beam.
3. Lower the closeout panel slightly, and carefully maneuver the left side of the closeout panel from above the driveline tunnel.
4. Insert the I/P courtesy lamp assembly up through the opening in the closeout panel.
5. Continue to lower the closeout panel, then pull to remove the closeout panel from the dash.
Installation Procedure
