Flex Plate: Specifications
- Make
- Chevrolet
- Model
- Avalanche 1500 2WD
- Engine
- V8-5.3L
- Year
- 2008
- Section
- Flex Plate › Specifications
Flex Plate: Specifications
Tighten the bolts (1-6) a first pass in sequence to ..................................................................................................................................... 20 N.m (15 lb ft).
Tighten the bolts (1-6) a second pass in sequence to ................................................................................................................................ 50 N.m (37 lb ft).
Tighten the bolts (1-6) a final pass in sequence to .................................................................................................................................. 100 N.m (74 lb ft).
