Cargo Lamp: Locations

Make

Chevrolet

Model

Avalanche 4WD

Engine

V8-5.3L

Year

2011

Section

Cargo Lamp › Locations

Lighting and HornsLocations · page 1 of 2

Cargo Lamp: Locations

Luggage Compartment/Rear of Vehicle Component Views

Rear Cargo Area Components (without E52 or TB7)

Engine Controls Schematics: ECM B, ECM

1 - Cargo Bed Lamp
2 - Remote Control Door Lock Receiver (RCDLR) (AP3 or AP8)
