Alignment: Description and Operation (page 4 of 7)

Make

Chevrolet

Model

Avalanche 4WD

Engine

V8-5.3L

Year

2011

Section

Alignment

MaintenanceDescription and Operation · page 4 of 7

1. For vehicles equipped with a torsion bar suspension, turn the bolt (1) that contacts the torsion bar adjusting arm as needed.
2. For vehicles without torsion bars, replace worn or damaged components as necessary.

D Height Measurement

1. Jounce the rear suspension of the vehicle by pushing the vehicle down and lifting up.
2. Allow the vehicle to settle and take a measurement.
