Steering Gear: Locations
Power Steering Gear Disassembled View
Disassembled View
1 - Steering Gear
2 - Steering Linkage Inner Tie Rod
3 - Steering Linkage Outer Tie Rod Nut
4 - Steering Linkage Outer Tie Rod
5 - Steering Linkage Inner Tie Rod Nut
6 - Outer Steering Gear Boot Clamp
7 - Steering Gear Boot
8 - Inner Steering Gear Boot Clamp
9 - Power Steering Assist Motor Bolt
10 - Power Steering Assist Motor
11 - Power Steering Assist Motor Seal
12 - Power Steering Assist Motor Label
13 - Power Steering Wiring Harness Extension Harness
14 - Plastic Tie Strap
15 - Power Steering Wiring Harness Extension Harness Retainer
16 - Power Steering Wiring Harness Extension Harness Retainer
