Aveo L4-1.6L (2008)

Page 9
background image

19. Install the air filter housing.
20. Install the air filter housing bolts.

Tighten the air filter housing bolts to 8 N.m (71 lb in).

21. Connect the air intake tube to the throttle body.
22. Connect the breather tube to the throttle body.
23. Connect the IAT sensor connector.
24. Connect the negative battery cable.
