Timing Component Alignment Marks: Locations
- Make
- Chevrolet
- Model
- Aveo
- Engine
- L4-1.6L
- Year
- 2008
- Section
- Timing Component Alignment Marks › Locations
MaintenanceLocations
Timing Component Alignment Marks: Locations
^
Align the timing mark on the crankshaft gear to the timing mark on the bottom of the rear timing belt cover.
Important: Ensure that the exhaust camshaft gear dowel pin is approximately in the 11 o'clock position.
^
Align the timing marks on the camshaft gears.
