Ignition Coil: Locations
- Make
- Chevrolet
- Model
- Cobalt
- Engine
- L4-2.4L
- Year
- 2007
- Section
- Ignition System › Ignition Coil › Locations
Powertrain ManagementLocations · page 1 of 7
Ignition Coil: Locations
Engine Controls Component Views
Front of the Engine (LE5)
Left Side View of Engine
1 - MAF/IAT Sensor
2 - Ignition Coil Module 1
3 - Ignition Coil Module 2
4 - Ignition Coil Module 3
5 - Ignition Coil Module 4
6 - Fuel Rail
7 - Fuel Injector 1
8 - Fuel Injector 2
9 - Fuel Injector 3
10 - Fuel Injector 4
11 - Throttle Actuator Control (TAC) Module
Rear View of Engine
