Grille: Service and Repair
Fascia Grille Replacement
Removal Procedure
1. Remove the front fascia assembly (3).
2. Remove the front fascia support.
3. Remove the radiator grille strap (2) from the back of the grille by depressing the grille strap fingers and pushing through the front of the grille.
4. Remove the screw from the bottom center of the grille.
5. Remove the grille from the front fascia by releasing the retainers around the perimeter of the grille.
Installation Procedure
