Dimmer Switch: Locations
Instrument Panel/Center Console Component Views
Instrument Panel and Console Components 1 of 3
1 - Ambient Light Sensor
2 - Instrument Panel Cluster (IPC)
3 - Driver Information Center (DIC) Switch
4 - Hazard Switch
5 - Inflatable Restraint Passenger Air Bag ON/OFF Indicator
6 - Rear Wiper/Washer/Fog Lamp Switch (T96)
7 - Radio
8 - HVAC Control Module
9 - Heated Seat Switch - Driver, Heated Seat Switch - Front Passenger
10 - Power Window Switch - Main
