Express 1500 RWD V8-5.3L (2008)

Page 1
background image

Flex Plate: Specifications

Automatic Transmission Flex Plate Bolts - First Pass .................................................................................................................................  20 N.m (15 lb ft)
Automatic Transmission Flex Plate Bolts - Second Pass ............................................................................................................................  50 N.m (37 lb ft)
Automatic Transmission Flex Plate Bolts - Final Pass ..............................................................................................................................  100 N.m (74 lb ft)
