HHR L4-2.4L (2010)
Dimmer Switch: Locations
Instrument Panel/Center Console Component Views
Instrument Panel (I/P) Components
1 - Ambient Light Sensor
2 - Driver Information Center (UAF)
3 - Hazard Switch
4 - Inflatable Restraint I/P Module
5 - Passenger Rear Access Panel Switch - Right Rear Panel (Panel Van)
6 - Inflatable Restraint I/P Module Indicator
7 - Radio/Navigation Unit
8 - HVAC Control Assembly
9 - Cigar Lighter (DT4)/Accessory Power Outlet I/P (- DT4)
10 - Rear Wiper/Washer Switch
11 - Fog Lamp Switch (T37 or T96)
12 - Traction Control Switch
13 - I/P Dimmer Switch
14 - Steering Wheel Controls - Right (UK3)
15 - Steering Wheel Controls - Left
16 - Driver Rear Access Panel Switch - Left Rear Panel (Panel Van)
17 - Driver Rear Access Panel Switch - Right Rear Panel (Panel Van)
18 - Turn Signal/Multifunction Switch
19 - Inflatable Restraint Steering Wheel Module
20 - Instrument Panel Cluster (IPC)
21 - WindshieldWiper/Washer Switch
