Wiper Switch: Locations
Instrument Panel/Center Console Component Views
Steering Column Components
1 - Turn Signal / Multifunction Switch
2 - Inflatable Restraint Steering Wheel Module Coil
3 - Windshield Wiper / Washer Switch
4 - Ignition Lock Control Actuator (MN5)
5 - Power Steering Control Module (PSCM)
6 - Steering Angle Sensor
7 - Electronic Power Steering (EPS) Motor
8 - Ignition Switch
Instrument Panel (I/P) Components
