Blower Motor: Locations
Instrument Panel/Center Console Component Views
Interior HVAC Components
1 - HVAC Module
2 - Mode Actuator
3 - Air Temperature Actuator (C67), Air Temperature Actuator - Right (CJ3)
4 - Recirculation Actuator
5 - Blower Motor
6 - Blower Motor Control Module
7 - Air Temperature Actuator - Left (CJ3)
