Wiper Motor: Locations

Make

Chevrolet

Model

Impala

Engine

V6-3.9L

Year

2007

Section

Wiper Motor › Locations

Wiper and Washer SystemsLocations

Wiper Motor: Locations

Wiper/Washer Component Views

LF of the Engine Compartment

LF of the Engine Compartment

1 - Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor
2 - Brake Booster Vacuum Sensor (LS4)
3 - Windshield Wiper Motor
4 - Electronic Brake Control Module (EBCM)
5 - A/C Refrigerant Pressure Sensor
6 - Transmission Control Module (TCM)
7 - Engine Control Module (ECM)
8 - G101
9 - Inflatable Restraint Front End Sensor - Left
