Water Pump: Specifications – Chevrolet Malibu L4-2.2L (2007)

Water Pump: Specifications

Position the water pump against the engine block and hand tighten the water pump bolts.
Install the inner water pump sprocket bolts. After 2 are snug, remove the guide pin and install the 3rd bolt.

Water Pump Bolts
Tighten the bolts to .....................................................................................................................................................................................  25 N.m (18 lb ft)

Water Pump Sprocket Bolt
Tighten the water pump sprocket bolts last.
Tighten the bolts to .....................................................................................................................................................................................  10 N.m (89 lb in)
