Malibu L4-2.2L (2007)
Alignment: Service and Repair
Front Camber Adjustment
Front Camber Adjustment
1. Reach around the tire, using the appropriate extension and socket.
2. Loosen both strut to knuckle nuts just enough to allow for movement.
3. If the strut has not been modified previously, perform the following steps before continuing with the wheel alignment:
1. Disconnect the strut from the knuckle.
2. File the lower hole until the outer flange slot matches the inner flange slot.
3. Connect the strut to the knuckle.
