Power Window Switch: Locations

Window Systems Component Views

Left Front Door

1 - Door Lock Switch - Driver
2 - Outside Rearview Mirror - Driver
3 - Outside Rearview Mirror - Switch
4 - Speaker - LF Door Tweeter (UZ6)
5 - Window Switch - Driver
6 - Speaker - LF Door
7 - Rear Compartment/Liftgate Release Switch
8 - Window Motor - Driver
9 - Door Latch Assembly - Driver

Right Front Door
