Knock Sensor: Locations

Make

Chevrolet

Model

Malibu

Engine

L4-2.4L

Year

2010

Section

Ignition System › Knock Sensor › Locations

Powertrain ManagementLocations · page 1 of 6

Knock Sensor: Locations

Powertrain Component Views

Lower Front and Rear of the Engine Components (LAT or LE5 or LE9)

1 - Knock Sensor (KS)
2 - Heated Oxygen Sensor (HO2S) 1
3 - Heated Oxygen Sensor (HO2S) 2
4 - Engine Coolant Temperature (ECT) Sensor

Lower Front and Rear of the Engine Components (LY7)
