Malibu V6-3.6L (2010)
Power Seat Switch: Locations
Passenger Compartment/Roof Component Views
Seat Components - Driver
1 - Seat Back Cover - Driver
2 - Heated Seat Element - Driver Back (KA1)
3 - Seat Back Cushion Pad - Driver
4 - Seat Recline Motor - Driver (1LZ)
5 - Seat Horizontal Motor - Driver (AG1 or 1LZ)
6 - Seat Rear Vertical Motor - Driver (AG1 or 1LZ)
7 - Heated Seat Control Module - Driver (KA1)
8 - Seat Front Vertical Motor - Driver (AG1 or 1LZ)
9 - Seat Recline Switch - Driver (1LZ)
10 - Seat Adjuster Switch - Driver
11 - Seat Belt Switch - Driver
12 - Seat Cushion - Driver
13 - Heated Seat Element - Driver Cushion (KA1)
14 - Seat Cover - Driver
Seat Components - Passenger
