Power Distribution Module: Locations

Luggage Compartment/Rear of Vehicle Component Views

Rear Window Shelf Components

1 - Cellular (UE1) and Digital Radio Antenna (U2K)
2 - Radio Antenna Module
3 - Remote Start Antenna (AP3)
4 - Speaker - Right Rear
5 - Accessory AC/DC Power Control Module (KV1)
6 - Audio Amplifier (UQ3)
7 - Rear Compartment Courtesy Lamp
8 - Remote Control Door Lock Receiver (RCDLR)
9 - Digital Radio Receiver (U2K)
10 - Speaker - Left Rear
