Malibu Classic L4-2.2L (2008)
Timing Component Alignment Marks: Locations
Timing Component Alignment Marks
^
Install the crankshaft sprocket with timing mark at the 5 o'clock position.
^
Lower the timing chain through the opening in the top of the cylinder head. Carefully ensure that the chain goes around both sides of the cylinder
block bosses (1, 2).
^
Install the intake camshaft sprocket with the INT diamond at the 2 o'clock position.
^
Hand tighten a NEW intake camshaft sprocket bolt.
