Tracker 4WD L4-2.0L VIN C (1999)
Actuator: Service and Repair
Removal Procedure
1. Raise and suitably support the vehicle. Refer to Vehicle Lifting.
2. Disconnect the actuator pump assembly electrical connector.
3. Remove the bolts (1) and the actuator pump assembly.
Installation Procedure
1. Install the actuator pump assembly and bolts (1) to the vehicle.
2. Connect the actuator pump assembly electrical connector.
