Circuit Breaker: Diagrams

Component ID:

53

Component :

CIRCUIT BREAKER

Connector:

Name :

CIRCUIT BREAKER

Color :
# of pins :

2

Pin

Description

Circuit

  1

ACCESSORY DELAY RELAY OUTPUT

F981 12PK/YL

  2

FUSED ACCESSORY DELAY RELAY OUTPUT

F30 14PK/YL
