Concorde V6-3.5L VIN F (1994)
Air Duct: All Technical Service Bulletins
Heat Distribution Duct - Service Precautions
NO: 24-22-93
GROUP: Heater & A/C
DATE: Sep. 3, 1993
SUBJECT:
Installation of Heat Distribution Duct
MODELS:
1993 - 1994 (LH) Concorde/Intrepid/LHS/New Yorker/Vision
DISCUSSION:
The right or left hand lower distribution duct securing clip(s) may be damaged when duct is removed from the vehicle. Installation of a damaged clip (or
failure to re-install) may result in duct becoming dislodged during vehicle use.
PARTS REQUIRED:
AR
Push-Pin Fastener
6501925
Quantity Required:
(2) RH Lower Distribution Duct
(1) LH Lower Distribution Duct
SERVICE PROCEDURE:
Prior to installing the right or left hand lower distribution duct, inspect the push-pin fastener (P/N 6501925) for any visual damage caused during its
removal. Replace fastener if any damage is detected.
POLICY: Information Only
