Pacifica V6-3.8L VIN L (2005)
Exhaust Manifold: Service and Repair
Exhaust Manifold - Right
EXHAUST MANIFOLD - RIGHT
REMOVAL
1) Disconnect battery negative cable.
2) Raise and support the vehicle.
3) Separate the exhaust pipe at the exhaust manifold.
4) Remove bolts fastening crossover pipe to exhaust manifold (Fig. 162).
5) Lower the vehicle.
6) Remove the air cleaner housing.
7) Disconnect the TPS, IAC and purge vacuum hose from the throttle body (Fig. 163).
8) Disconnect the upstream oxygen sensor (Fig. 163).
9) Disconnect the spark plug wires at the spark plugs.
10) Remove bolts attaching exhaust manifold to cylinder head and remove manifold (Fig. 163).
11) Inspect and clean manifold.
CLEANING
